- Motor type: DVR direct drive (without belt)
- Power 1 HP (750 watts)
- Working area diameter: 16" = 406 mm
- Distance drilling center - column / projection: 203 mm
- Drilling depth: 115mm (spindle stroke)
- Distance spindle - work table approx. 321 mm
- Distance spindle - base approx. 575 mm
- Quill diameter approx. 60 mm
- Installation dimensions HxDxW 1,150 x 525 x 365 mm
- Table dimensions 320 x 320 mm
- Work table can be swiveled and rotated
- Speed 150 - 3,000 rpm (adjustable to 5,000 rpm)
- Spindle taper: MK2
- Drill chuck span: 1-16 mm
- Left/right rotation
- Weight approx. 70 kg (table version)
